Main Unit

• Machine Type
  A4 Monochrome Multifunctional
• Core Functions
  Print, Copy, Scan, Send, Store and optional Fax
• Processor Speed
  1.8GHz Dual Core Processor
• Control Panel
  10.1" TFT LCD WSVGA Color Touch panel
• Memory
  RAM 4.5GB
• Storage
  Standard: (SSD) 256GB
• Interface Connection
  Network
  Standard: 1000Base-T/100Base-TX/10Base-T,
  Optional: Wi-Fi(IEEE 802.11a/b/g/n/ac/ax)
  Others
  Standard: USB 2.0 x 1 (Host), USB 3.0 x 1 (Host), USB 2.0 x 1 (Device)
  Optional: Serial Interface, Copy Control Interface
• Paper Supply Capacity (A4, 80 gsm)
  Standard: 650 sheets
  100-sheets Multi-purpose tray
  550-sheets Paper cassette x 1
  Maximum: 3,200 sheets (with High Capacity Cassette Feeding Unit-D1)
• Paper Output Capacity (A4, 80 gsm)
  500 sheets
• Finishing Capabilities
  Collate, Group
• Supported Media Types
  Multi-purpose tray:
  Thin, Plain, Recycled, Color, Heavy, Bond, Transparency, Letterhead,Envelope
  Paper Cassette:
  Thin, Plain, Recycled, Color, Heavy, Bond, Label, Pre-Punched, Letterhead
• Supported Media Sizes
  Multi-purpose tray:
  Standard size: A4, A5, A5R, A6, B5
  Custom size: 76.2 x 127.0 mm to 216.0 x 355.6 mm
  Envelope: COM10 No.10, Monarch, DL, ISO-C5

  Paper Cassette:
  Standard size: A4, A5, A5R, A6, B5
  Custom size: 99.0 x 148.0 mm to 216.0 x 297.0 mm
• Supported Media Weights
  Multi-purpose tray: 60 to 200 gsm
  Paper Cassette: 60 to 135 gsm
  Duplex: 60 to 120 gsm
• Warm-up Time
  Quick Start-up Mode: 4 Seconds or less*
  From Sleep Mode: 10 seconds or less
  From Power On: 10 seconds or less**

  *Time from device power-on to when key operations can be performed on the touch panel display.
  **Time from device power-on, until copy ready
  (not print reservation)
• Dimensions (W x D x H)
  500 x 598 x 617 mm
• Installation Space (W x D)
  1,052 x 823 mm (with left CRG door open + right door open + the cassette drawer open)
• Weight
  Approx. 36kg including toner

Print Specifications

• Print Speed
  1-sided: up to 71 ppm (A4), up to 113 ppm (A5), up to 40 ppm (A5R, A6)
  2-sided: up to 58 ppm (A4), up to 33 ppm (A5R)
• Print Resolution (dpi)
  Up to 1,200 x 1,200
• Page Description Languages
  Standard: UFR II, PCL6/PCL5, Adobe® PostScript®3TM
• Double-Sided Printing
  Standard
• Direct Print

  Supported file types: PDF, EPS, TIFF/JPEG, and XPS

• Mobile / Cloud Printing
  AirPrint, Mopria, IPP Everywhere, Canon PRINT, uniFLOW Online, Universal Print and Cloud Connector

  A range of software and MEAP-based solutions are available to provide printing from mobile devices or internet-connected devices and cloud-based services depending on your requirements.
  Please contact your sales representative for further information
• Fonts
  PS fonts: 136 Roman
  PCL fonts: 93 Roman, 10 Bitmap fonts, 2 OCR fonts, Andalé Mono WT J/K/S/T* (Japanese, Korean, Simplified and Traditional Chinese), Barcode fonts**

  * Optional PCL International Font Set-A1 is required.
  ** Optional Barcode Printing Kit-D1 is required.
• Print Features
  Secured Print, Secure Watermark, Header/Footer, Page Layout, Two-sided Printing, Mixed Paper Sizes/Orientations, Front/Back Covers, Toner Reduction, Poster Printing, Forced Hold printing, Print Date, Scheduled Printing, Printing Using a Virtual Printer
• Operating Systems
  UFRII: Windows® 10/11/Server2016/Server2019/Server2022/Server2025, macOS (10.14 or later)
  PCL: Windows® 10/11/Server2016/Server2019/Server2022/Server2025
  PS: Windows® 10/11/Server2016/Server2019/Server2022/Server2025, macOS (10.14 or later)
  PPD: Windows® 10/11, macOS (10.15 or later)

  As of June 2025

Copy Specifications

• Copy Speed
  1-sided: up to 71 ppm (A4), up to 113 ppm (A5), up to 40 ppm (A5R, A6)
  2-sided: up to 58 ppm (A4), up to 33 ppm (A5R) :
• First-Copy-Out Time
  Approx. 5 seconds or less
• Copy Resolution (dpi)
  600 x 600
• Multiple Copies
  Up to 9,999 copies
• Magnification
  Variable zoom: 25% to 400% (1% Increments)
• Basic Copy Features
  Preset R/E Ratios by Area, Two-Sided, Density Adjustment, Original Type Selection, Interrupt Mode, Two-sided Original, Job Build, N on 1, Page Numbering, Copy Set Numbering, Sharpness, Erase Frame, Secure Watermark, Print Date, Copy ID Card, Skip Blank Pages, Reserved copy, Copy Sample

Scan Specifications

• Type
  Single-pass Duplexing Automatic Document Feeder* [2-sided to 2-sided (Automatic)]
  With Multi-Sheet Feed Detection
• Pull Scan Specifications
  Colour Network ScanGear2 for both TWAIN and WIA
• Scan Resolution (dpi)
  600 x 600
• Document Feeder Paper Capacity (80 gsm)
  up to 100 Sheets
• Acceptable Originals/Weights
  Document Feeder media weight:
  1-sided scanning: 42 to 128 gsm (BW), 64 to 128 gsm (CL)
  2-sided scanning: 50 to 128 gsm (BW), 64 to 128 gsm (CL)

  Note:
  Business card: 80 to 220 gsm
  Original width narrower than A6: 50 to 128 gsm
  Long Original(over than 355.6mm): 60 to 90gsm
• Supported Media Sizes
  Platen: up to 216.0 x 355.6 mm

  Document Feeder:
  A4, A5R, A6, B5, Custom size: 48.0 x 128.0 mm to 216.0 x 355.6 mm
  Business card: 48.0 x 85.0 mm to 55.0 x 91.0 mm
• Scan Method
  Push Scan, Pull Scan, Scan to Box, Scan to Advanced Space, Scan to Network, Scan to USB Memory Key, Scan to Mobile devices, Scan to cloud (uniFLOW Online / Cloud Connector*)
  *optional.
• Scan Speed
  Send (300 x 300 dpi):
  up to 95/190 when Automatic Colour Select “OFF”:
  1-sided Scanning: 95
  2-sided Scanning: 190
  Automatic Color Select "ON":
  1-sided Scanning: 50
  2-sided Scanning: 100

  Copy (600 x 600 dpi, BW only):
  1-sided Scanning: 95
  2-sided Scanning: 140
• Double-Sided Scanning
  Yes

Send Specifications

• Optional / Standard
  Standard
• Destination
  Standard: E-mail/Internet FAX (SMTP*), SMB3.0, FTP, WebDAV, Mail Box
  Optional: Super G3 FAX, IP Fax

  * OAuth 2.0 authentication method is available for Microsoft 365 and Google Workspace
• Address Book / Speed Dials
  LDAP (2,000)/Local (1,600)/Speed dial (200)
• Communication Protocol
  File: FTP(TCP/IP), SMB3.1.1 (TCP/IP), WebDAV
  E-mail/I-Fax: SMTP, POP3
• File Format
  TIFF, JPEG, PDF (Compact, Searchable, Optimize for Web, PDF A/1-b, Trace & Smooth, Encrypted, Device Signature, User Signature), XPS (Compact, Searchable, Device Signature, User Signature), Office Open XML (PowerPoint, Word)
• Universal Send Features
  Original Type Selection, Two-sided Original, Density Adjustment, Sharpness, Erase Frame, Job Build, Delayed Send, Preview, Job Done Notice, File Name, Subject/Message, Reply-to, E-mail Priority, TX Report, Original Content Orientation, Skip Blank Originals

Fax Specifications

• Optional / Standard
  Optional
• Maximum Number of Connection Lines
  1
• Modem Speed
  Super G3: 33.6 kbps
  G3: 14.4 kbps
• Compression Method
  MH, MR, MMR, JBIG
• Resolution (dpi)
  400x400 (Ultra Fine), 200x400 (Super Fine), 200x200 (Fine), 200x100 (Normal)
• Sending/Receiving Size
  Sending: A4, A5R*, A6* , B5*
  Receiving: A4, A5*, A5R , B5

  *Sent as A4
• FAX Memory
  Up to 30,000 pages (2,000 jobs)
• Speed Dials
  Max. 200
• Group Dials/Destinations
  Max. 199 dials
• Sequential Broadcast
  Max. 256 addresses
• Memory Backup
  Yes
• Fax Features
  Sender's Name (TTI), Selecting the Telephone Line (when sending fax), Direct Send, Delayed Send, Preview, Job Done Notice, TX Report, Interrupt Transmission, Sequential Broadcasting, Password/Subaddress Sending, Confidential Mailbox, 2 on 1 Log

Store Specifications

• Mail Box
  100 User Inboxes,
  1 Memory RX Inbox,
  50 Confidential Fax Inboxes
  Maximum 30,000 Pages (2,000 jobs) Stored
• Advanced Space
  Communication Protocol: SMB or WebDAV
  Supported Client PC: Windows®10/11
  Concurrent Connections (Max.): SMB:64, WebDAV:3
• Advanced Space Available Disk Space
  Standard: 16 GB
• Advanced Space Features
  Authentication for Advanced Space Log-in, Sort Function, Printing a PDF File with a Password, Search, File Preview, Authentication Management, Open to public, URI TX, Backup/Restore

Security Specifications

• Authentication & Access Control
  User Authentication (Picture Login, Picture and PIN Login, Card Login*, Username and Password Login, Function Level Login, Mobile Login), Department ID Authentication (Department ID and PIN Login, Function Level Login), uniFLOW Online** (PIN Login, Picture Login, Picture and PIN Login, Card Login, Card and PIN Login, Username and Password Login, Department ID and PIN Login, Function Level Login), Cloud Connector** (PIN Login), Microsoft Entra ID (PIN Login, Card Login), Two-Factor Authentication at LUI/RUI, Access Management System (Access Control)

  *Card readers are optional, please refer to Hardware Accessories
  **Subscription required
• Network Security
  TLS 1.3 (FIPS140-3), IPSec (FIPS140-3), IEEE802.1X authentication, SNMPv3, Firewall Functionality (IP/MAC Address Filtering), Dual Network Support (Wired LAN/Wireless LAN, Wired LAN/Wired LAN), WPA3 support (Wi-Fi), Enabling/Disabling (Network Applications, Remote UI, USB Interface), G3 FAX separation from LAN, USB Port separation from LAN, Prohibit the execution of files stored in Advanced Space in the MFP, Scan and Send -Virus Concerns for E-mail Reception
• Document Security
  Print Security (Secure Print, Encrypted Secure Print, Forced Hold Printing, uniFLOW Secure Print*), Receive Data Security (Confidential Fax Inbox Forwarding Received Documents Automatically), Scan Security (Encrypted PDF, Device Signature PDF/XPS, User Signature PDF/XPS, BOX Security (Mail Box Password Protected, Advanced Space Access Control), Send Data Security (Setting for requesting password input per transmission, Restricted E-mail/File send functions, Confirming FAX number, Allow/Restrict Fax Driver Transmissions, Allow/Restrict Sending from History, S/MIME Support), Document Tracking (Secure Watermark)

  * Requires uniFLOW Online / uniFLOW
• Device Security
  Protecting SSD Data [SSD Data Encryption (FIPS140-3), SSD Lock], Standard SSD Initialize, Initialize (NIST 800-88 PURGE LEVEL), Trusted Platform Module (TPM 2.0), Job Log Conceal Function, Protecting MFP Software Integrity: Verify System at Startup (NIST SP800-193: Protection), Checking MFP Software Integrity & Platform Firmware Resiliency: Automatic System Recovery (NIST SP800-193: Recovery), Runtime Intrusion Detection: Trellix Embedded Control, HCD-PP Common Criteria Certification*

  *Validation pending
• Device Management & Auditing
  Administrator Password, Digital Certificate and Key Management, Audit Log, Cooperating with External Security Audit System (Security Information and Event Management), Image Data Logging, Security Policy Setting

Environmental Specifications

• Operating Environment
  Temperature: 10 to 30 ºC
  Humidity: 20 to 80 % RH (Relative Humidity/No condensation)
• Power Source
  220-240 V, 50/60 Hz, 4.8 A
• Power Consumption
  Maximum: Approx. 1500 W
  Copy mode (ADF continuation copying): 834.29W*1
  Standby: Approx 32.40 W*1
  Sleep mode: Approx. 0.36 W*2
  *1 Reference value: measured one unit
  *2 0.36 W is not available in all circumstances due to certain settings
  Typical Electricity Consumption (TEC)* rating: 0.73 kWh
  *ENERGY STAR (US scheme), Eligibility Criteria Version 3.2 for Imaging Equipment
• Noise Levels
  Sound Power Level (LWA,m)*
  Active (BW)(1-sided): 69dB, Kv 3dB*
  Sound Pressure (LpAm)* Bystander’s position:
  Active(BW/CL)(1-sided): 56 dB
  Stand-by: 21 dB*

  * Reference value: measured only one unit with ISO7779, described with ISO9296 (2017)
• Standards
  Blue Angel (Validation Pending)

Software & Printer Management

• Tracking & Reporting
  uniFLOW Online (optional)
• Remote Management Tools
  iW Enterprise Management Console
  Remote Distribution & Management Service
  Monitoring Service
• Scanning Software
  Colour Network ScanGear 2
• Optimisation Tools
  Canon Driver Configuration Tool
• Platform
  MEAP (Multifunctional Embedded Application Platform)

Consumables

• Toner Cartridge/s
  T03 Black
• Toner Estimated Yield
  51,500 pages
  Toner Cartridge yield in accordance with ISO/IEC 19752.

Paper Supply Options

• Cassette Feeding Unit
  Cassette Module-AG1
  Paper Capacity: 550 sheets (80 gsm)
  Paper Type: Thin, Plain, Recycled, Heavy, Color, Label, Bond, Pre-punched, Letterhead
  Paper Size: A4, A5, A5R, A6, B5, Custom size: 99.0 x 148.0 mm to 216.0 x 355.6 mm
  Paper Weight: 60 to 135 gsm

  Envelope Cassette Module-A1
  Paper Capacity: 75 sheets (Envelope)
  Envelope Size: COM10 No.10, Monarch, DL, ISO-C5
  Paper Weight: 80 to 100 gsm

  Cassette Feeding Unit-AR1
  Paper Capacity: 550 sheets (80 gsm)
  Paper Type: Thin, Plain, Recycled, Heavy, Color, Label, Bond, Pre-punched, Letterhead
  Paper Size: A4, A5, A5R, A6, B5, Custom size: 99.0 x 148.0 mm to 216.0 x 355.6 mm
  Paper Weight: 60 to 135 gsm

  Cassette Feeding Unit-AX1
  Paper Capacity:
  First Cassette 550 sheets (80gsm)
  2nd cassette 550 sheets (80gsm)
  3rd cassette 550 sheets (80gsm)
  Paper Type: Thin, Plain, Recycled, Heavy, Color, Label, Bond, Pre-punched, Letterhead
  Paper Size: A4, A5, A5R, A6, B5, Custom size: 99.0 x 148.0 mm to 216.0 x 355.6 mm
  Paper Weight: 60 to 135 gsm
• High Capacity Cassette Feeding Unit
  High Capacity Cassette Feeding Unit-D1
  Upper cassette:
  Paper Capacity: 550 sheets (80 gsm)
  Paper Type: Thin, Plain, Recycled, Heavy, Color, Label, Bond, Pre-punched, Letterhead
  Paper Size: A4, A5, A5R, A6, B5, Custom size: 99.0 x 148.0 mm to 216.0 x 355.6 mm
  Paper Weight: 60 to 135 gsm

  Lower cassette:
  Paper Capacity: 2,000sheets (80 gsm)
  Paper Type: Thin, Plain, Recycled, Heavy, Color, Bond, Pre-punched
  Paper Size: A4
  Paper Weight: 60 to 135 gsm

Hardware Accessories

• Card Readers
  IC Card Reader Box-D2

  Various card readers are available, please contact local Canon Office for more details.
• Others
  Plain Pedestal Type-W2
  Plain Pedestal Type-X2

System & Controller Options

• Print Accessories
  PCL International Font Set-A1
• Barcode Printing
  Barcode Printing Kit-D1
• System Accessories
  Copy Control Interface Kit-A1
  Wireless LAN Attachment Kit-B1
• Fax Accessories
  Super G3 FAX Board-BM1
  Remote Fax Kit-A1
  IP FAX Expansion Kit-B1
