Main Unit

• Machine Type
  A3 Monochrome Multifunctional
• Core Functions
  Print, Copy, Scan, Send, Store and Optional Fax
• Processor Speed
  1.8GHz Dual Core Processor
• Control Panel
  10.1" TFT LCD WSVGA Colour Touch panel
• Memory
  RAM: 6GB
• Storage
  Standard: (SSD) 256GB
  Optional: (SSD) 1TB
• Interface Connection
  NETWORK
      Standard: 1000Base-T/100Base-TX/10Base-T
      Optional: Wireless LAN (IEEE 802.11a/b/g/n/ac/ax)
  OTHERS
       Standard: USB 2.0 (Host) x1, USB 3.0 (Host) x1, USB 2.0 (Device) x1
      Optional: Serial Interface, Copy Control Interface
• Network Protocols
  File: FTP(TCP/IP), SMB3.0 (TCP/IP), WebDAV
  E-mail/I-Fax: SMTP, POP3
• Paper Supply Capacity (A4, 80 gsm)
  Standard: 1.200 sheets
       100-sheet Multi-purpose tray x 1
       550-sheet Paper cassette x 2
  Maximum: 6,350 sheets (with High Capacity Cassette Feeding Unit-F1 + Paper Deck Unit-F2)
• Paper Output Capacity (A4, 80 gsm)
  Maximum: 3,450 Sheets (with Staple Finisher-AB3 or Paper Folding/Booklet Finisher-A2 and 3rd Copy Tray Kit-A1)
• Finishing Capabilities
  Collate, Group, Offset, Staple, Saddle Stitch, Hole Punch, Eco Staple, Staple On Demand, V-fold, C-fold, Z-fold

  * Finishing capabilities vary depending on the options connected
• Supported Media Types
  Multi-purpose tray:
  Thin, Plain, Recycled, Eco, Colour, Heavy, Coated, Tracing, Bond, Transparency, Label, Pre-punched, Letterhead, Tab, Envelope, Water Resistant
• Supported Media Sizes
  Multi-purpose tray:
  Standard size: SRA3, A3, A4, A4R, A5, A5R, A6R, B4, B5, B5R
  Custom size: 98.0 x 139.7 mm to 320.0 x 457.2 mm
  Free Size: 98.0 x 139.7 mm to 320.0 x 457.2 mm
  Envelopes: COM 10 No.10, Monarch, DL, ISO-C5
  Envelope custom size: 98.0 x 90.0 mm to 320.0 x 457.2 mm
• Supported Media Weights
  Multi-purpose tray: 52 to 300 gsm

  Paper Cassette (Upper): 52 to 256 gsm
  Paper Cassette (Lower): 52 to 300 gsm

  Duplex: 52 to 256 gsm
• Warm-up Time
  Quick Startup Mode: 4 Seconds or less *

  * Time from device power-on to when the copy icon appears and is enabled to operate on the touch panel display

  From Sleep Mode: 7 Seconds or less

  From Power On: 6 Seconds or less*

  * Time from device power-on, until copy ready (not print reservation)
• Dimensions (W x D x H)
  620 x 722 x 937 mm
• Installation Space (W x D)
  Basic: 1,050 x 1,162 mm (Right Cover Open with Multi-purpose tray extended + Cassette Drawers Open)
  Fully Configured: 2,044 x 1,162 mm (Staple Finisher-AB3/Paper Folding/Booklet Finisher-A2 with the extension tray extended + Paper Folding Unit-L1 + Paper Deck Unit-F2 + Cassette Drawers open)
• Weight
  Approx. 94 kg

Print Specifications

• Print Speed
  up to 70 ppm (A4, A5*, A5R, A6R*), up to 36 ppm (A3), up to 42 ppm (A4R)

  *1-sided only
• Print Resolution (dpi)
  4,800 x 2,400
• Page Description Languages
  Standard: UFR II, PCL6
  Optional: Adobe® PostScript®3TM
• Double-Sided Printing
  Yes
• Direct Print
  Supported file types: PDF, EPS, TIFF/JPEG, and XPS
• Mobile / Cloud Printing
  AirPrint, Mopria, Canon PRINT Business, Canon PRINT, uniFLOW Online* and Universal Print by Microsoft, Cloud Connector*

  A range of software and MEAP-based solutions are available to provide printing from mobile devices or internet-connected devices and cloud-based services depending on your requirements.
  Please contact your sales representative for further information

  *optional
• Fonts
  PS fonts: 136 Roman
  PCL fonts: 93 Roman, 10 Bitmap fonts, 2 OCR fonts, Andalé Mono WT J/K/S/T* (Japanese, Korean, Simplified and Traditional Chinese), Barcode fonts**

  * Optional PCL International Font Set-A1 is required
  ** Optional Barcode Printing Kit-D1 is required
• Print Features
  Secured Print, Secure Watermark, Header/Footer, Page Layout, Two-sided Printing, Mixed Paper Sizes/ Orientations, Front/Back Covers, Toner Reduction, Poster Printing, Forced Hold printing, Print Date, Scheduled Printing, Printing Using a Virtual Printer
• Operating Systems
  UFRII: Windows® 10/11/Server2016/Server2019/Server2022/Server 2025, macOS (10.14 or later)
  PCL: Windows® 10/11/Server2016/Server2019/Server2022/Server 2025
  PS: Windows® 10/11/Server2016/Server2019/Server2022/Server 2025, macOS (10.14 or later)
  PPD: Windows® 10/11/Server2016/Server2019/Server2022/Server 2025, macOS (10.14 or later)

  As of Dec 2024

Copy Specifications

• Copy Speed
  up to 70 ppm (A4, A5*, A5R, A6R), up to 36 ppm (A3), up to 42 ppm (A4R)

  * 1-sided only
• First-Copy-Out Time
  Approx. 2.7 seconds or less
• Copy Resolution (dpi)
  600 x 600
• Multiple Copies
  Up to 9,999 copies
• Magnification
  Variable zoom: 25% to 400% (1% Increments)
• Special Copy Features
  Preset R/E Ratios by Area, Two-Sided, Sort, Density Adjustment, Original Type Selection, Interrupt Mode, Book to Two Pages, Two-sided Original, Job Build, N on 1, Add Cover, Insert Sheets, Different Size Originals, Page Numbering, Copy Set Numbering, Sharpness, Erase Frame, Secure Watermark, Print Date, Gutter, Print & Check, Negative/Positive, Repeat Images, Merge Job Blocks, Mirror Image, Store in Mail Box, Superimpose Image, Copy ID Card, Skip Blank Pages, Free Size Original, Reserved copy, Copy Sample

Scan Specifications

• Type
  Single-pass Duplexing Automatic Document Feeder* [2-sided to 2-sided (Automatic)]

  * Multi-Sheet Feed detection is supported
• Pull Scan Specifications
  Colour Network ScanGear2. For both TWAIN and WIA
• Scan Resolution (dpi)
  600 x 600
• Acceptable Originals/Weights
  Document Feeder media weight:

  1-sided scanning: 38 to 220 gsm (BW, CL)
  2-sided scanning: 38 to 220 gsm (BW, CL)

  *An acceptable weights of A6R or smaller is 50 to 220gsm
• Scan Method
  Push Scan, Pull Scan, Scan to Box, Scan to Advanced Space, Scan to Network, Scan to USB Memory Key, Scan to Mobile devices, Scan to cloud* (uniFLOW Online & Cloud Connector)

  *optional
• Scan Speed
  1-sided Scanning:
  135/135 ipm (300 x 300 dpi, send), 80/80 ipm (600 x 600 dpi, copy)
  2-sided Scanning:
  270/270 ipm (300 x 300 dpi, send), 160/90 ipm (600 x 600 dpi, copy)
• Double-Sided Scanning
  Yes

Send Specifications

• Optional / Standard
  Standard
• Destination
  Standard: E-mail/Internet FAX (SMTP*), SMB3.0, FTP, WebDAV, Mail Box
  Optional: Super G3 FAX, IP Fax

  * OAuth 2.0 authentication method is available for Microsoft 365 and Google Workspace
• Address Book / Speed Dials
  LDAP (2,000)/Local (1,600)/Speed dial (200)
• Send Resolution (dpi)
  1-sided Scanning:
  135/135 (300 x 300 dpi, send), 80/80 (600 x 600 dpi, copy)
  2-sided Scanning:
  270/270 (300 x 300 dpi, send), 160/90 (600 x 600 dpi, copy)
• Communication Protocol
  File: FTP(TCP/IP), SMB 3.1.1 (TCP/IP), WebDAV
  E-mail/I-Fax: SMTP, POP3
• File Format
  TIFF (MMR), JPEG*, PDF (Compact, Searchable, Apply policy, Optimize for Web, PDF/A-1b, Trace & Smooth, Encrypted, Device Signature, User Signature), XPS (Compact, Searchable, Device Signature, User Signature), Office Open XML (PowerPoint, Word)

  *Single page only
• Universal Send Features
  Original Type Selection, Two-sided Original, Book to Two Pages, Different-size Originals, Density Adjustment, Sharpness, Copy Ratio, Erase Frame, Job Build, Delayed Send, Preview, Job Done Notice, File Name, Subject/Message, Reply-to, E-mail Priority, TX Report, Original Content Orientation, Skip Blank Pages

Fax Specifications

• Optional / Standard
  Optional
• Maximum Number of Connection Lines
  2
• Modem Speed
  Super G3: 33.6 kbps
  G3: 14.4 kbps
• Compression Method
  MH, MR, MMR, JBIG
• Resolution (dpi)
  400 x 400 (Ultra Fine), 200 x 400 (Super Fine), 200 x 200 (Fine), 200 x 100 (Normal)
• Sending/Receiving Size
  Sending: A3, A4, A4R, A5*, A5R*, A6R*, B4, B5**, B5R*
  Receiving: A3, A4, A4R, A5, A5R, B4, B5, B5R

  * Sent as A4
  ** Sent as B4 short
• FAX Memory
  Up to 30,000 pages (2,000 jobs)
• Speed Dials
  Max. 200
• Group Dials/Destinations
  Max. 199 dials
• Sequential Broadcast
  Max. 199 dials
• Memory Backup
  Max. 256 addresses
• Fax Features
  Sender's Name (TTI), Selecting Telephone Line (when sending fax), Direct Send, Delayed Send, Preview, Job Done Notice, TX Report, Interrupt Transmission, Sequential Broadcasting, Password/Subaddress Sending, Confidential Mailbox, 2 on 1 Log

Store Specifications

• Mail Box
  100 User Inboxes,
  1 Memory RX Inbox,
  50 Confidential Fax Inboxes
  Maximum 10,000 Pages (2,000 jobs) Stored
• Advanced Space
  Communication Protocol: SMB or WebDAV
  Supported Client PC: Windows® 10/11
  Concurrent Connections (Max.): SMB:64, WebDAV:3
• Advanced Space Available Disk Space
  Standard: 16 GB
  (With option: max. 480GB)
• Advanced Space Features
  Authentication for Advanced Space Log-in, Sort Function, Printing a PDF File with a Password, Search, File Preview, Authentication Management, Open to public, URI TX, Backup/Restore

Security Specifications

• Authentication & Access Control
  User Authentication (Picture Login, Picture and PIN Login, Card Login*, Username and Password Login, Function Level Login, Mobile Login), Department ID Authentication (Department ID and PIN Login, Function Level Login), uniFLOW Online** (PIN Login, Picture Login, Picture and PIN Login, Card Login, Card and PIN Login, Username and Password Login, Department ID and PIN Login, Function Level Login), Cloud Connector** (PIN Login), Microsoft Entra ID (PIN Login, Card Login), Two-Factor Authentication at LUI/RUI, Access Management System (Access Control)

  *Card readers are optional, please refer to Hardware Accessories
  **Subscription required
• Network Security
  TLS 1.3, IPSec, IEEE802.1X authentication, SNMP V3.0, Firewall Functionality (IP/MAC Address Filtering), Dual Network Support (Wired LAN/Wireless LAN, Wired LAN/Wired LAN), Enabling/Disabling (Network Applications, Remote UI, USB Interface), G3 FAX separation from LAN, USB Port separation from LAN, Prohibit the execution of files stored in Advanced Space in the MFP, Scan and Send -Virus Concerns for E-mail Reception
• Document Security
  Print Security (Secure Print, Encrypted Secure Print, Forced Hold Printing, uniFLOW Secure Print*), Receive Data Security (Confidential Fax Inbox Forwarding Received Documents Automatically), Scan Security (Encrypted PDF, Device Signature PDF/XPS, User Signature PDF/XPS, BOX Security (Mail Box Password Protected, Advanced Space Access Control), Send Data Security (Setting for requesting password input per transmission, Restricted E-mail/File send functions, Confirming FAX number, Allow/Restrict Fax Driver Transmissions, Allow/Restrict Sending from History, S/MIME Support), Document Tracking (Secure Watermark)

  * Requires uniFLOW Online / uniFLOW
• Device Security
  Protecting SSD Data [SSD Data Encryption (FIPS140-3), SSD Lock], Standard SSD Initialize, Initialize (NIST 800-88 PURGE LEVEL), Trusted Platform Module (TPM 2.0), Job Log Conceal Function, Protecting MFP Software Integrity: Verify System at Startup (NIST SP800-193: Protection), Checking MFP Software Integrity & Platform Firmware Resiliency: Automatic System Recovery (NIST SP800-193: Recovery), Runtime Intrusion Detection: Trellix Embedded Control, HCD-PP Common Criteria Certification*

  *validation pending
• Device Management & Auditing
  Administrator Password, Digital Certificate and Key Management, Audit Log,
  Cooperating with External Security Audit System (Security Information and Event Management), Image Data Logging, Security Policy Setting

Environmental Specifications

• Operating Environment
  Temperature: 10 to 30 ºC
  Humidity: 20 to 80 % RH (Relative Humidity)
• Power Source
  220-240 V, 50/60 Hz, 6 A
• Power Consumption
  Maximum: Approx. 2000 W
  Copying (with DADF continuous scan): Approx. 908 W*1
  Standby: Approx. 42.5 W *1
  Sleep mode: Approx. 0.5 W*2
  Typical Electricity Consumption (TEC)*¹: 0.75 kWh

  *1 Reference value: measured one unit
  *2 0.5 W is not available in all circumstances due to certain settings
• Noise Levels
  Sound Power Level (LWA,m)*
  Active (1-sided): XX 66 dB, Kv X 3 dB*
  Sound Pressure (LpAm)*
  Bystander's position:
  Active (1-sided): 51 dB
  Stand-by: 18 dB*

  * Reference value: measured only one unit with ISO7779, described with ISO9296 (2017)
• Standards
  Blue Angel

Software & Printer Management

• Tracking & Reporting
  uniFLOW Online (optional)
• Cloud Connectivity
  uniFLOW Online / Cloud Connector (optional)
• Remote Management Tools
  iW Enterprise Management Console
  Monitoring Service
  Remote Distribution & Management Service
• Scanning Software
  Colour Network ScanGear 2
• Optimisation Tools
  Canon Driver Configuration Tool
• Platform
  MEAP (Multifunctional Embedded Application Platform)
• Document Publishing
  PowerPDF Advanced (Optional)

Consumables

• Toner Cartridge/s
  Toner 1002 BK
• Toner Estimated Yield
  Toner (Estimated Yield @ 5% Coverage)
  Toner 1002 BK: 65,500 pages

Paper Supply Options

• Cassette Feeding Unit
  Cassette Feeding Unit-AY1
  Paper Capacity: Paper Capacity: 2 x 550 sheets (80 gsm)
  Paper Type: Thin, Plain, Recycled, Eco, Colour, Heavy, Bond, Transparency, Pre-punched, Letterhead
  Paper Size: A3, A4, A4R, A5, A5R, A6R, B4, B5, B5R
                Custom size: 98.0 x 148.0 mm to 304.8 x 457.2 mm
  Paper Weight: 52 to 300 gsm
• High Capacity Cassette Feeding Unit
  High Capacity Cassette Feeding Unit-F1
  Paper Capacity: 2,450 sheets (80 gsm)
  Paper Type: Thin, Plain, Recycled, Eco, Colour, Heavy, Bond, Pre-punched, Letterhead
  Paper Size: A4
  Paper Weight: 52 to 300 gsm
• Paper Deck
  Paper Deck Unit-F2
  Paper Capacity: 2,700 sheets (80 gsm)
  Paper Type: Thin, Plain, Colour, Recycled, Heavy, Pre-punched
  Paper Size: A4, B5
  Paper Weight: 52 to 256 gsm

Output Options

• Copy Tray
  1st Copy Tray Kit-B1
  Capacity (with 80gsm paper):
       A4, A5, A5R, A6R, B5: 250 sheets
       SRA3, A3, A4R, B4, B5R: 100 sheets
       Long sheet*:
       Length up to 990.0 mm: 20 sheets (151 to 163 gsm)
       Length up to 1,300.0 mm: 1 sheet (151 to 163 gsm)
  Paper Weight: 52 to 300 gsm

  * Long Sheet Catch Tray-D1 is required.
• Inner 2-Way Tray
  Inner 2way Tray-M1
  Tray Capacity (with 80 gsm paper)
     Upper tray: A4, A5, A5R, A6R, B5: 100 sheets
              SRA3, A3, A4R, B4, B5R: 50 sheets
    Lower tray (standard tray): A4, A5, A5R, A6R, B5: 250 sheets
               SRA3, A3, A4R, B4, B5R: 100 sheets
  Paper Weight: 52 to 300 gsm
• Inner Finisher
  Inner Finisher-N1
  Tray Capacity (with 80gsm paper):
    Upper Tray: SRA3, A3, A4, A4R, A5, A5R, A6R, B4, B5, B5R : approx. 45 sheets
            long sheet length of up to 900.0 mm: 1 sheet
    Lower Tray: A4, A5, A5R, B5: approx. 500 sheets
            A3, A4R, B4, B5R: 250 sheets
            A6R: 30 sheets
            SRA3, Envelope: 10 sheets
  Paper Weight: 52 to 300 gsm
  Staple Position: Corner, Double
  Staple Capacity: (52 to 90 gsm)
    A4, B5: 50 sheets
    A4R: 40 sheets
    A3, B4: 30 sheets
  Eco Staple:
    A3, A4, B4, B5: 10 sheets (52 to 64 gsm)
            8 sheets (65 to 81.4 gsm)
            6 sheets (82 to 105 gsm)
  Staple On Demand: approx. 40 sheets (80 gsm)
• 3rd Copy Tray Kit
  3rd Copy Tray Kit-A1
  Capacity (with 80gsm paper):
    A4, A5R, B5: 100 sheets
    A3, A4R, B4, B5R: 75 sheets
  Paper Weight: 52 to 300 gsm
• Staple Finisher
  Staple Finisher-AB3
  (Requires Buffer Pass Unit-R1)
  Tray Capacity (with 80gsm paper):
    Upper Tray: A4, A5, A5R, A6R, B5: approx. 250 sheets
            SRA3, A3, A4R, B4, B5R: approx. 125 sheets
    Lower Tray: A4, A5, A5R, B5: 3,000 sheets
            SRA3, A3, A4R, B4, B5R: 1,500 sheets
            A3, B4 (Z-fold*): 30 sheets
            A4R (Z-fold*): 10 sheets
            A6R: 250 sheets
            Envelopes: Monarch: 30 sheets, COM10 No.10, DL, ISO-C5: 100 sheets
  Paper Weight:
    Upper Tray: 52 to 256 gsm
    Lower Tray: 52 to 300 gsm
  Staple Position: Corner, Double
  Staple Capacity: (52 to 90 gsm)
     A4, B5: 65 sheets
     A4R: 40 sheets
     A3, B4: 30 sheets
  Eco Staple:
     A3, A4: 10 sheets (52 to 64 gsm)
          8 sheets (65 to 81.4 gsm)
          6 sheets (82 to 105 gsm)
  Staple On Demand: 65 sheets (52 to 90 gsm)

  * Paper Folding Unit-L1 is required.
• Booklet Finisher
  Paper Folding/Booklet Finisher-A2
  (Requires Buffer Pass Unit-R1)
  (Includes the above Staple Finisher-AB3 basic staple specifications.)
  Saddle Stitch paper size: A3, A4R, B4
  Saddle Stitch Staple Capacity: 20 sheets x 10 sets (52 to 81.4 gsm) (including 1 cover sheet 52 to 256 gsm)
  V-fold Capacity: up to 5 sheets (52 to 105 gsm)
  C-fold Capacity:
    up to 6 sheets (52 to 90 gsm)
    up to 5 sheets (91 to 128 gsm)
• Paper Folding
  Paper Folding Unit-L1
  (Requires Buffer Pass Unit-R1)
  Paper size: A3, A4, B4
• Inner 4 Hole Puncher
  Inner 2/4 Hole Puncher-D1
  (Requires the Inner Finisher-N1)
  Two or Four Holes
  Acceptable Punch Paper Weight: 52 to 300 gsm
  Acceptable Punch Paper Size:
    Two holes: A3, A4, A4R, A5, B4, B5, B5R
    Four holes: A3, A4
• Inner 4 Hole Puncher
  Inner 4 Hole Puncher-D1
  (Requires the Inner Finisher-N1)
  Four Holes
  Acceptable Punch Paper Weight: 52 to 300 gsm
  Acceptable Punch Paper Size:
    Four holes: A3, A4, A4R, A5, B4, B5, B5R
• 2/4 Hole Puncher Unit
  2/4 Hole Puncher Unit-A1
  (Requires either the Staple Finisher-AB3 or Paper Folding/Booklet Finisher-A2)
  Two or Four Holes
  Acceptable Punch Paper Weight: 52 to 300 gsm
  Acceptable Punch Paper Size:
    Two holes: A3, A4, A4R, A5, B4, B5, B5R
  Four holes: A3, A4
• 4 Hole Puncher Unit
  4 Hole Puncher Unit-A1
  (Requires either the Staple Finisher-AB3 or Paper Folding/Booklet Finisher-A2)
  Four Holes
  Acceptable Punch Paper Weight: 52 to 300 gsm
  Acceptable Punch Paper Size:
  Four holes: A3, A4, A4R, A5, B4, B5, B5R

Hardware Accessories

• Card Readers
  Copy Card Reader-F1
  IC Card Reader Box for Numeric Keypad-A1
  Copy Card Reader Attachment-B7
• Others
  Printer Cover-M2
  Utility Tray-B1
  Numeric Keypad-A2
  Buffer Pass Unit-P2
  Long Sheet Catch Tray-D1
  Plain Pedestal Type-Q3

Security Options

• Data Security
  256GB SSD-A1
  1TB SSD-A1
  Memory Mirroring Kit-A1

System & Controller Options

• Print Accessories
  PCL International Font Set-A1
  Barcode Printing Kit-D1
• System Accessories
  Wireless LAN Board-H1
  Wireless LAN 5GHz License-A1@E
  Copy Control Interface Kit-A1
  Serial Interface Kit-K3
• Fax Accessories
  Super G3 FAX Board-AX2
  Remote Fax Kit-A1
  IP FAX Expansion Kit-B1

Other Options

• Staple Cartridge
  Staple Cartridge-X1/Y1/Z1
• Accessibility Accessories
  ADF Access Handle-A1
  Voice Operation Kit-D1
