Basic / Digital PPC
• Type Desktop
• Copy / Print Process Laser / Electrostatic photographic method
• Process Dry type single component imaging
• Warm-up Time Approx. 35 sec.
• First Copy Time 4.5 sec.
• Resolution 600 dpi
• Gray Scale 256 steps
• Multi Copy Speed 25 cpm
• Maximum Original Size Ledger
• Copy Size Ledger, Legal, Letter, Invoice
• Copy Ratio Enlargement (fixed) 200%, 155%, 129%, 121%
• Reduction (fixed) 79%, 77%, 65%, 61%, 50%
• Zoom (variable) 25 ~ 400%
• Automatic Document Feeder (Option) 50 sheets (Letter) / 30 sheets (Ledger, Legal)
• Paper Feed 550-sheet paper feed module x 2 + 50-sheet bypass
• Max. : 2,250 sheets with optional paper feed module x 2
• Quantity Selector 1-999, Automatic reset to 1
• Exposure Control Text, Photo/Text, Photo
• Page Memory Capacity 18 MB (plus 16 MB with optional ADU)
• Sorting Memory Capacity 8 MB
• Optional Memory for Electronic Sort Base Memory plus 8 MB / 16 MB / 128 MB
• Power Requirements 99 - 138 V AC 47 - 63 Hz Single phase
• Power Consumption Max. : Less than 1.5 kW
• Sleep mode: Approx. 1.8 w
• Dimensions (H x W x D) 27.6" x 23.5" x 23.6"*10 (701 x 597 x 600 mm)
• Weight (Excluding optional equipment) 121 lbs*10 (55 kg)
Printer / Scanner (DA-PC200)
• Printer Interface Bi-directional Parallel (IEEE 1284)
• Printing Speed 25 ppm
• Printing Resolution 600 dpi
• Scanning Resolution 600 dpi (Local)
• Scanner Driver TWAIN
• OS Windows NT® 4.0 / Windows® 2000 / 98 / 95
• Page Description Language PCL6 Emulation (with optional PCL6 Emulation Kit)
G3 Fax (DA-FG230)
• Compatibility ITU-T Group 3, ECM
• Modem Speed 33,600 – 2,400 bps with automatic fallback
• Coding Scheme JBIG / MMR / MR / MH
• Transmission Speed Approx. 3 second / page *11
• Scanning Speed 0.7 sec. (Letter portrait in Standard or Fine mode)
• Scanning Standard: 203 dots/inch x 98 lines/inch (8 dots/mm x 3.85 lines/mm)
• Resolution Fine: 203 dots/inch x 196 lines/inch (8 dots/mm x 7.7 lines/mm)
• Super Fine: 406 dots/inch x 391 lines/inch (16 dots/mm x 15.4 lines/mm)
• Effective Scanning Width 11.5" (292 mm)
• Recording Resolution Max. 406 dots/inch x 391 lines/inch
• Image Memory Capacity Approx. 120 pages*12
• Optional Memory Base memory plus 320 pages (4 MB) / 640 pages (8 MB)*12
Internet Fax (DA-NE200)
• Compatibility IETF RFC 2305, ITU-T T.37
• Communication Protocol TCP/IP, SMTP, POP3, MIME
• Network Connectivity 100BASE-TX / 10BASE-T Ethernet [IEEE 802.3]
• Data Format TIFF-FX Profile S, MMR (400 dpi only)
