GENERAL

Control Panel

10.1” Colour WVGA Touch Screen Tilting Display

Dimensions & Weight

955 x 698 x 1,227 mm (W x D x H), 213 kg

Paper Size & Weight

Cassettes: A5R-320 x 460 mm, 60-256 gsm. Tandem LCF*: A4, 60-256 gsm. Bypass: 100 x 148 mm-330 x 483 mm, 60-300 gsm, banner paper (up to 313.4 x 1,200 mm, 90-163 gsm)

Controller Type

Toshiba e-BRIDGE Next

Warm-up Time

Approx. 15 Seconds from low power mode

Paper Capacity

2x 540 sheets. (Cassettes) + 1x 2,320 sheets (Tandem LCF)*, 1x 120 sheets (Bypass). Maximum 6,020 sheets

Memory

Toshiba Secure HDD 320 GB**, 4 GB RAM

Print Speed

Colour: 55 ppm (A4), Mono: 65 ppm (A4)

Automatic Duplex

A5R-320 x 460 mm, 60-256 gsm

Interface

10Base-T/100Base-TX/1000Base-T, High Speed USB 2.0, WLAN*** (IEEE802.11b/g/n), Bluetooth***, Wi-Fi Direct***

PRINT

Resolution

600 x 600 dpi, 1,200 x 1,200 dpi (2 bit, PostScript driver only), 3,600 x 1,200 dpi with smoothing (PostScript driver only, monochrome)

Page Description Languages

PCL5e, PCL5c, PCL6 (PCL XL), XPS and PostScript 3 compatible

Print Functions

Universal Printer Driver, Driver Templates, Driver plug-ins*, Print from USB, Hold print, Tandem printing

Supported Systems

Windows 10/8/7/Vista/Server 2008 (32/64 bit), Windows Server 2012/Server 2008 R2 (64 bit), Mac OS X 10.6.8-10.11, Linux/Unix, Citrix, Novell NetWare (NDPS), SAP, AS/400

SCAN

Scan Functions

WS Scan, Scan to USB, Scan to E-Mail, Scan to File (SMB, FTP, FTPS, IPX/SPX, Local), Meta Scan***, OCR scan***, Scan to Box (e-Filing), WIA, TWAIN

Resolution

600 dpi, 400 dpi, 300 dpi, 200 dpi, 150 dpi, 100 dpi

Scan Speed

up to 240 ipm (300 dpi) in colour and monochrome via Dual Scan Document Feeder

Scan Modes

Auto-Colour (ACS), Colour, Greyscale, Monochrome

File Formats

JPEG, Multi/Single Page TIFF/XPS/PDF, Secure PDF, Slim PDF, PDF/A, Searchable PDF*** (and other formats like DOCX, XLSX)***

FAX

Transmission Speed

Approx. 3 seconds per page

Incoming Fax Routing

To shared folders (SMB, FTP, IPX/SPX), E-Mail, e-Filing

Communication

Super G3, G3 - (opt. 2nd line)

Network Fax

Driver for Windows 10/8/7/Vista/Server 2008 (32/64 bit), Server 2012/Server 2008 R2 (64 bit)

Compression

MH/MR/MMR/JBIG

COPY

Resolution

Scan: 600 x 600 dpi Print: 600 x 600 dpi, 2,400 x 600 dpi with smoothing

Colour Modes

Auto-Colour (ACS), Full Colour, Twin Colour, Mono Colour, Monochrome

First Copy Output Time

Colour: Approx. 6.4 seconds. Monochrome: Approx. 5.2 seconds

Colour Settings

Hue, Saturation, Colour Balance, RGB adjustment, 5 one-touch modes

Zoom

25-400% (Platen), 25-200% (DSDF)

Copy Modes

Text, Text/Photo, Photo, Printed Image, Map, Image Smoothing

Copy Functions

Electronic Sort, Rotate Sort, ID Card Copy, Edge Erase, 2-in-1 / 4-in-1 mode
